System Architecture
Explore the architecture behind Hyper Edge 500 — a fully integrated, clustered HCI system with unified compute, storage, and networking. Built for speed, resilience, and simplicity.
Designed for Real Cloud Infrastructure
Hyper Edge 500 is more than hardware — it’s a full-scale cloud platform in a 3-node HCI cluster, engineered to deliver high performance, multitenancy, and zero vendor lock-in.
The system combines:
3 × 1U nodes forming a single resilient cluster
200 Gbps internal networking fabric
Integrated NVMe storage with Ceph-based replication
Dedicated cold spare for continuity
Preloaded with the MomentumX OpenStack-based control plane
Hyperconverged by Design
Hyperconverged infrastructure means compute, storage, and networking are:
- Software-defined: abstracted from the hardware layer
- Unified: managed via a single web UI or API
- Integrated: provisioned together and scaled together
- Flexible: support for VMs, containers, volumes, and snapshots
Hyper Edge 500 takes this further by delivering the entire stack — pre-clustered, optimized, and tested.
Node-Level Architecture
Each 1U server includes:
- Dual AMD EPYC CPUs
- DDR5 memory up to 6 TB
- Up to 16 NVMe drives
- Redundant power and cooling
- Dual 100 Gbps NICs
- Optional full-height GPU(s)
The three nodes communicate over a dedicated 200 Gbps fabric, eliminating east-west bottlenecks and ensuring high availability across workloads.
Internal Topology
Compute Plane Handles all
VM/container workloads with hardware-assisted virtualization
Storage Plane
NVMe-only Ceph pool, with snapshotting, thin provisioning, replication.
Network Plane
Isolated tenant networks with NAT, VLANs, routing, floating IPs.
Control Plane
Full lifecycle management (provisioning, scaling, monitoring).
Failover Fabric
Node-aware redundancy with optional cold spare integration.
Cluster Management & Resilience
Node-aware workload distribution
- Auto-failover to available capacity
- Hot-add of compute or storage nodes
- Cold spare node can be activated with zero reconfiguration
- Live migration and cluster snapshots supported
- Granular monitoring across CPU, RAM, storage, and network
Designed for Edge and Datacenter
3U total cluster (3 active + 1 spare)
100% rack-compatible (standard depth)
Front-to-back airflow and low power draw
Web-based remote management
Secure boot, RBAC, and encrypted control plane
Operable in harsh, remote, or space-constrained environments
Cloud Without Complexity
Unlike legacy HCI vendors that require licensing stacks, external storage, or complex upgrades, Hyper Edge 500 is fully turnkey:
- No need for separate SANs or external orchestrators.
- No third-party licensing or renewals
- No multi-week integrations or hidden dependencies.
- Delivered as a single unit — plug in and launch VMs
Built Like a Cloud Region. Delivered in 3U.
Explore the internal architecture of Hyper Edge 500 and see how we’ve built a simplified, high-performance HCI solution that’s ready to deploy in weeks — not months.
